XtremeRGB Range
XtremeRGB is the range for capturing legacy analogue RGB, DVI and SD composite/S-Video sources — common in medical imaging suites still running older modalities, digital signage estates, machine vision and industrial equipment with analogue outputs. Channel counts run from one (XtremeRGB-Ex1+) up to eight (XtremeRGB-Ex8), with mixed SD-plus-DVI options (XtremeRGB-Ex4+) and dedicated dual-SDI (XtremeRGB-SDI2) variants for projects that need to consolidate several older sources onto as few PCIe slots as possible.
Watch the range overview
XtremeAV and XtremeRGB mixed-signal capture cards
DVI, analogue RGB, composite, S-Video and SDI sources in one modern system: the nine mixed-signal cards in three groups, and where they fit.
Plays from YouTube when you press play. Watch on YouTube
Not sure which capture range fits your source signal? See our buyer's guide in the Knowledge Base.
SKU: XRGB-SDI2
XtremeRGB-SDI2
- Loop-through SDI BNC connections
- All 3G/HD/SD modes up to 1080p60
- Dual channel PCIe capture
- Four-lane PCIe, up to 650 MB/s
SKU: XRGB-EX4
XtremeRGB-Ex4+
- HD via supplied DVI/Component or DVI/HDMI adapter
- Four SD channels — PAL/NTSC/SECAM, composite or S-Video
- Four-lane PCIe, up to 650 MB/s
- Windows & Linux support
SKU: XRGB-EX8
XtremeRGB-Ex8
- High performance DMA with scatter-gather
- On-board processor for real-time mode/sync detection
- PAL, NTSC, SECAM, composite and S-Video
- Dynamic input source selection
SKU: XRGB-EX2
XtremeRGB-Ex2+
- High performance DMA, direct-to-graphics-memory option
- On-board processor, real-time mode/sink detection
- Dynamic input source selection, admin mode
- HD up to 1080p60; DVI up to 1920×1200
SKU: XRGB-EX1
XtremeRGB-Ex1+
- Four-lane PCIe, up to 650 MB/s
- On-card processor, real-time mode/sink detection
- Up to 32 capture channels across multiple cards
- Analog RGB up to 2048×1536 x24bit
Key points
Capture DVI, analogue RGB/VGA, YPbPr, composite and S-Video — the sources digital-only cards cannot take
From one channel up to eight on a single card, to save PCIe slots
Works in a single PC with the EMS unified Windows & Linux driver, or inside a VSN video wall controller
Standard 3-year warranty
Frequently Asked Questions
What's the difference between XtremeAV and XtremeRGB?
XtremeAV mixes HD and SD capture with audio on one card — for example DVI-I plus composite — and includes the quad DVI-I Xtreme-HD4. XtremeRGB covers DVI and analogue RGB capture (Ex1+, Ex2+), mixed SD plus DVI/RGB (Ex4+), eight-channel SD (Ex8) and dual SDI (SDI2).
Do I need a video wall controller?
No. Each card works in a standard PC with PCIe slots. They can also be fitted in a VSN chassis when the sources feed a video wall.
Which card for 4K60 HDMI, DisplayPort or 3G-SDI?
For current 4K60 digital sources, see the Digital Capture Cards (XtremeDV).
